Match more than the advertised screen size
A bracket's diagonal range is a starting filter. Compatibility also depends on the TV's weight without its stand, the mounting-hole pattern, the hardware and the shape of the back panel. Find the exact model number and compare the TV manual with the mount specifications.
Read the VESA measurements
VESA spacing is the horizontal distance followed by the vertical distance between the mounting holes, in millimeters. A 400 × 300 pattern means 400 mm across and 300 mm vertically. Check that both dimensions are explicitly supported by the bracket; a similar-looking rectangle is not enough.
Check screws and physical clearance
The correct screw diameter, thread and engagement depth come from the TV instructions. Bracket thickness and any specified spacers affect the overall screw length. A screw that starts threading can still be too long or too short. Do not force a screw or substitute a guessed spacer arrangement.
Confirm that the rails do not block power, HDMI sockets, vents or a raised section on the back. Also check whether the mounting hardware will protrude beyond the television's edges.
Separate TV compatibility from wall compatibility
A bracket can fit the television and still be unsuitable for the wall. Review the permitted wall construction and attachment method in the mount manual. An articulating bracket adds demands when extended; its load rating does not make every wall or anchor suitable.
For a compatibility check, send photos of the TV's model label, the bracket label and the intended wall. If you already own the mount, keep its manual and all supplied parts together for the appointment.
Reusing a bracket during a TV replacement
For a Gilroy project, we replaced an older 65″ Sony with a 75″ Samsung above a fireplace and reused the existing Sanus tilting bracket. The soundbar, DirecTV and Blu-ray player were reconnected as part of the setup.
This is an example of reuse for a particular combination of equipment. A larger replacement TV does not automatically require a new bracket, and an existing bracket is not automatically suitable. Compare the new TV’s weight and VESA pattern with the bracket specifications, then check the required hardware, available adjustment and the condition of the attachment.
Keep both model labels available. Our guide to choosing the right TV mounting screws explains why screw diameter and engagement need their own check.
